EE / M Product Group

M 20 - M 74 / E 70 - E 80 Horizontal

M-Core / E-Core Coil Formers

Horizontal coil formers for larger M-core and E-core transformer geometries.

Request QuoteRequest Sample

Technical Group Data

Group Characteristics.

Technical characteristics, article variants and verified product resources are consolidated at group level for fast engineering and procurement access.

Core Range

M 20 - M 74 / E 70 - E 80

Orientation

Horizontal

Materials

Material selection depending on variant and requirement

RTI

Depending on selected material

Pin System

Pins or solder blades depending on configuration

Soldering Resistance

+350°C up to 2 seconds depending on configuration

Application

Power transformers and industrial applications

Benefit

Supports larger transformer geometries and robust assemblies

Technical product overview · 79 verified article entries

Article Level

Available NORWE Types.

Select the required NORWE type by order code. Verified technical resources are linked to the article context so drawings, samples and quotations can be handled without losing product identity.
