EE / M Product Group

EE 8 - EE 32 Vertical

Vertical EE Coil Formers

Vertical EE coil formers for upright PCB assembly and transformer applications.

Request QuoteRequest Sample

Technical Group Data

Group Characteristics.

Technical characteristics, article variants and verified product resources are consolidated at group level for fast engineering and procurement access.

Core Range

EE 8 - EE 32

Orientation

Vertical

Materials

PA66 p6g, PA66 A RV250 natural, PA66 A3X2G10 black, PA66 x2g5, PBT pcg

RTI

+100°C to +130°C depending on material

Pin System

Tin bronze, tin-plated pins

Soldering Resistance

+350°C up to 2 seconds

Application

Transformers and electronic assemblies

Benefit

Vertical board assembly with reliable winding geometry

Technical product overview · 27 verified article entries

Article Level

Available NORWE Types.

Select the required NORWE type by order code. Verified technical resources are linked to the article context so drawings, samples and quotations can be handled without losing product identity.

Need Support With This Product Group?

Talk to NORWE about EE 8 - EE 32 Vertical, article selection, drawings, samples or quotation preparation.

Start Technical Inquiry
