EE / M Product Group

EE 8 - EE 32 Horizontal

Horizontal EE Coil Formers

Horizontal EE coil formers for compact transformers, SMPS and power transfer applications.

Request QuoteRequest Sample

Technical Group Data

Group Characteristics.

Technical characteristics, article variants and verified product resources are consolidated at group level for fast engineering and procurement access.

Core Range

EE 8 - EE 32

Orientation

Horizontal

Materials

PA66 p6g, PA66 A RV250 natural, PA66 A3X2G10 black, PA66 x2g5, PBT pcg

RTI

+100°C to +130°C depending on material

Pin System

Tin bronze, tin-plated pins

Soldering Resistance

+350°C up to 2 seconds

Application

Small transformers, SMPS, converters

Benefit

Compact geometry and reliable winding support

Technical product overview · 81 verified article entries

Article Level

Available NORWE Types.

Select the required NORWE type by order code. Verified technical resources are linked to the article context so drawings, samples and quotations can be handled without losing product identity.

Need Support With This Product Group?

Talk to NORWE about EE 8 - EE 32 Horizontal, article selection, drawings, samples or quotation preparation.
